Stadium 350W

Product Code : LVN-128-PRJ350STD

350W LED Stadium Projector

General Features Technical Specifications Applications Standarts Technical Drawing
  • Perfect Mold Design, Integrated Pressure Die-Casting Aluminum.
  • Flat-Elegant Design, Excellent Heat Dissipation.
  • Light / Energy High Efficiency.
  • SDCM ( Standard Deviation Colour Matching ) <5.
  • Beam Angle ;  7°- 15°- 30°- 60°- 90°- 120°- 30° x 90°- Type II-Type III
  • 1-10V / DALI / D4i / Smart Timer Dimming.
  • LED Driver Thermal Protection.
  • Robotic Electrostatic Powder Coating.
  • Paint Code RALXXXX, which can change according to customer request.
  • IK10 Aluminum Body.
  • IK08 Tempered Glass.
  • Pressure Balancing Valve that creates Airflow to eliminate moisture inside.
  • Ease of Installation.
  • Our products are Brand and Design Registered.

Product Code
Body
Power
Input Voltage Range
Power Factor
Total Harmonic (I)
LED Pieces
Lumen
Color Temperature
Color Rendering Index ( CRI )
LED (LM80) Life
DIMM
Operating Temperature
Lighting Angle
IP Class
Insulation Class
Front Side
Vertical Adjust Angle
Weight
Dimensions
Warranty Period
Model I
LVN-128-PRJ350STD
Aluminum Injection
350W
100-277 AC 50/60Hz
0,98
<4%
128 High Power / 5050 / 3535
52095*
3000-4000-5000-6500K
70 Ra / 80 Ra / 90 Ra / TLCI
L70B10@85°C >102Kh
1-10V/DALI/STD Option
-30 / +50 °C
7°- 15°- 30°- 60°- 90°- 120°- 30° x 90°
IP 66
Class I
4mm Tempered Glass
0° - 135°
10,1 kg
377 x 531 x 129 mm
3 / 5 year













































 * Lumen Values are given for 5000K 5050 & CRI 70.

  • Stadium Lighting

  • Soccer Fields Lighting

  • Indoor Sports Facilities Lighting

  • Airport Apron Lighting

  • Ship Port Lighting

  • Sport Field Lighting

  • Bridge Lighting

  • Warehouse and Stock Area Lighting

  • Consturaction Sites Lighting

  • EN 60598-1

  • EN 60598-2-5

  • EN 12193

  • LM79

  • LM80 & TM21

  • CE
